Monel 400 Pipe Fittings, Monel Alloy 400 Elbow, Alloy 400 Reducer Manufacturer

Nickel Alloy 400 Cross In Singapore, Monel 400 Two Joint Pipe Fittings, UNS N06400 Pipe Fittings, Monel 400 Stub End, Monel® Alloy 400 LR Elbow, Monel 400 Equal Tee In Indonesia, 2.4360 Reducer, Monel Alloy 400 Pipe Cap Stockist Supplier in Mumbai, India.

It is a commercially natural shape of metallic and isn't problem to embrittlement or lack of corrosion resistance within the heat - affected zones that influences many different instantly chromium alloys. It have to be mentioned that the strength of it will increase all of sudden underneath 900 Degree C. Various welding strategies in our Monel Alloy WNR 2.4361 Dish Cap Pipe Fittings are relevant within the identical way as with the same old austenitic steels, together with shielded metallic arc welding, TIG welding, and plasma welding. The excessive - temperature strength of these Pipe Fittings is essentially similar to metallic within the variety of 950 Degree C – 1150 Degree C.

It has more desirable pitting and crevice corrosion resistance in assessment with the normal austenitic or metallic sorts and is appropriate to be used in competitive environments. It has first rate resistance to pressure corrosion cracking and offers an excessive resistance to erosion corrosion and corrosion fatigue. Solution annealing in these Nickel Alloy 400 Cross Pipe Fittings have to be executed after hot working, wherein that is because of the better additions of chromium, molybdenum and nitrogen. Furthermore, it has substantially progressed structural balance as compared with preceding alloys, main to fewer worries in the course of welding, fabrication, and service.

Material Specification Chart of Monel 400 Pipe Fittings

Specifications	ASTM B366 / ASME SB366
Dimensions	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
Size	Seamless Fittings : 1/2" - 10" Welded Fittings : 1/2" - 48"
Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D
Size Range	½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
Connection	Welding
Manufacturing Process	Push, Press, Forge, Cast, etc.
Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc
Specialized Manufacturer of	90 Deg. Elbows, 45 Deg. Elbow, Tee, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend

Monel 400 PIPE FITTINGS MANUFACTURING STANDARDS

ASTM B366/B366M	Piping Fittings
ASME B16.9	Factory-Made Wrought Fittings Buttwelding
MSS SP-43	Wrought & Fabricated Butt-Welding Fitting for Low Pressure, Corrosion Resistant Applications
BS3799 –	Specification for pipe fittings, Socket-welding and threaded/screwed fitting for the petroleum industry
ASTM B366 – ASME SB366	Standard Specification for Piping Fitting
ASME Standard	ASME/ANSI B16.9, ASME/ANSI B16.28, MSS-SP-43
DIN Standard	DIN28011, DIN2617, DIN2616, DIN2615, DIN2605
EN Standard	EN10253-2, EN10253-1
ASME B16.25	Buttwelding Ends
ASME B16.28	SR Elbows and Buttwelding Returns
API 590-605 ASME B16.9	‘Factory-Made Wrought Butt-welding Fittings’

Various Types Of Monel 400 Butt weld Pipe Fittings

Monel 400 Butt weld Elbow

Monel® Alloy 400 45 Degree Elbow
2.4360 Short Radius Elbow
Monel 400 90 Degree Elbow In Indonesia
Alloy 400 3D Butt weld Elbow
UNS N06400 LR Elbow
ANSI B16.9 Monel Alloy 400 5D Elbow
Nickel Alloy 400 180 Deg Elbow In Malaysia

Monel 400 Butt weld Tee

Monel® Alloy 400 Reducing Tee In Mexico
Monel 400 Tee In Philippines
UNS N06400 Butt weld Tee
Alloy 400 Equal Tee
Monel 400 Unequal Tee
ANSI B16.9 Monel 400 Buttweld Tee
2.4360 Buttweld Tees

Monel 400 Butt weld Cross

UNS N06400 Butt weld Cross
Monel Alloy 400 Unequal Cross
ANSI B16.9 Monel Alloy 400 Buttweld Cross
Monel 400 Reducing Cross In Japan
Alloy 400 Equal Cross
Monel 400 Cross In Italy
2.4360 Buttweld Cross

Monel 400 Concentric Reducer

Nickel Alloy 400 Concentric Reducer In Kuwait
UNS N06400 Concentric Reducer
Alloy 400 Concentric Reducer In Spain
2.4360 Concentric Reducer
ANSI B16.9 Monel Alloy 400 Concentric Reducer

Monel 400 Eccentric Reducer

ANSI B16.9 Monel Alloy 400 Eccentric Reducer
Alloy 400 Eccentric Reducer
2.4360 Eccentric Reducer
UNS N06400 Eccentric Reducer
Nickel Alloy 400 Eccentric Reducer In Singapore

Monel 400 Stub End

UNS N06400 Butt weld Stub End
ANSI B16.9 Monel Alloy 400 Lap Joint Stub End
Alloy 400 Long Stub End In Indonesia
2.4360 Short Stub End
Monel 400 Short Stub End In Singapore

Monel 400 Pipe End Cap

2.4360 End Pipe Cap
Monel 400 End Cap In Malaysia
Alloy 400 Pipe Cap In Kuwait
UNS N06400 Butt weld Cap
ANSI B16.9 Monel Alloy 400 Pipe End Cap

Monel 400 Pipe Nipple

ANSI B16.9 Monel Alloy 400 Barrel Nipple
Monel 400 Nipple In Mexico
2.4360 Swage Nipple
UNS N06400 Butt weld Nipple
Alloy 400 Pipe Nipple In Spain

Monel 400 Pipe Bend

Alloy 400 Piggable Bend In Italy
UNS N06400 Butt weld Bend
2.4360 Hot Induction Bend
Monel 400 Long Radius Bend In Philippines
ANSI B16.9 Monel Alloy 400 Bend

Equivalent Grades of Monel 400 Buttweld Fittings

View Thickness Table Of Monel 400 Buttweld Fittings, We have Global sales network for Monel 400 LR Elbow, Wide Stockist Of Werkstoff No 2.4360 Seamless Fittings In India.

ASTM B366 Monel 400 Buttweld Fittings

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
Monel 400	2.4360	N04400	NW 4400	NA 13	МНЖМц 28-2,5-1,5	NU-30M	NiCu30Fe

Seamless/ Welded 100% Radiography Tested
Products		Size
ASTM B366 Alloy 400 Elbow – Long Radius	ASTM B366 Alloy 400 45° Elbow	Sizes 1/2″ – 48″
ASTM B366 Alloy 400 Elbow – Short Radius	ASTM B366 Alloy 400 Cross
ASTM B366 Alloy 400 3D Elbow	ASTM B366 Alloy 400 5D Elbow
ASTM B366 Alloy 400 Stub End	ASTM B366 Alloy 400 Pipe Bend
ASTM B366 Alloy 400 Fabricated Tee	ASTM B366 Alloy 400 End Cap
ASTM B366 Alloy 400 Reducer	ASTM B366 Alloy 400 Tee
ASTM B366 Alloy 400 Reducing Elbow	ASTM B366 Alloy 400 Pipe Nipple
ASTM B366 Alloy 400 Reducing Cross	ASTM B366 Alloy 400 Eccentric Reducer
ASTM B366 Alloy 400 Concentric Reducer	ASTM B366 Alloy 400 Welded Fittings

Check available Sizes of ASME SB 366 Monel 400 Pipe Reducer, Ask For Ready Stock of UNS N06400 Stub End in Mumbai, India.

BAGODA

Quick Contact

Call Us

+91 22 - 66151721

Need Help? Send us Email

sales@bagodasteelproject.com

ASME B16.9 Monel 400 Short and Long Radius Elbows Dimensions

Nominal Pipe Size (inches)	Outside Diameter		45°Elbows		90° Elbows		180° Returns
	Outside Diameter		Long Radius		Long Radius	Short Radius	Long Radius
	(mm)	(inches)	Center to Face (inches)	Radius (inches)	Center to Face (inches)	Center to Face (inches)	Center to Center (inches)	Back to face (inches)
1	33.4	1.315	7/8		1 1/2	1	3	2 3/16
1/2	21.3	0.840	5/8		1 1/2	–	2	1 7/8
3/4	26.7	1.050	7/16		1 1/8	–	2 1/4	1 11/16
1 1/4	42.2	1.660	1		1 7/8	1 1/4	3 3/4	2 3/4
1 1/2	48.3	1.900	1 1/8	3	2 1/4	1 1/2	4 1/2	3 1/4
2	60.3	2.375	1 3/8	4	3	2	6	4 3/16
2 1/2	73.0	2.875	1 3/4	5	3 3/4	2 1/2	7 1/2	5 3/16
3	88.9	3.500	2	6	4 1/2	3	9	6 1/4
3 1/2	101.6	4.000	2 1/4	7	5 1/4	3 1/2	10 1/2	7 1/4
4	114.3	4.500	2 1/2	8	6	4	12	8 1/4
5	141.3	5.563	3 1/8	10	7 1/2	5	15	10 5/16
6	168.3	6.625	3 3/4	12	9	6	18	12 5/16
8	219.1	8.625	5	12	12	8	24	16 5/16
10	273.1	10.750	6 1/4	15	15	10	30	20 3/8
12	323.9	12.750	7 1/2	18	18	12	36	24 3/8

ASME B16.9 Monel 400 Tee & Cap Dimensions

Nominal Pipe Size (inches)	Outside Diameter		Caps	Straight Crosses	Straight Tees	Stub Ends
Nominal Pipe Size (inches)	(mm)	(inches)	Length (inches)	Center to End (inches)	Center to End (inches)	Lap Diameter (inches)	Long Length (inches)	Short Length (inches)
1	33.4	1.315	1 1/2	1 1/2	1 1/2	2	4	2
1/2	21.3	0.840	1	–	1	1 3/8	3	2
3/4	26.7	1.050	1	–	1 1/8	1 11/16	3	2
1 1/4	42.2	1.660	1 1/2	1 7/8	1 7/8	2 1/2	4	2
1 1/2	48.3	1.900	1 1/2	2 1/4	2 1/4	2 7/8	4	2
2	60.3	2.375	1 1/2	2 1/2	2 1/2	3 5/8	6	2 1/2
2 1/2	73.0	2.875	1 1/2	3	3	4 1/8	6	2 1/2
3	88.9	3.500	2	3 3/8	3 3/8	5	6	2 1/2
3 1/2	101.6	4.000	2 1/2	3 3/4	3 3/4	5 1/2	6	3
4	114.3	4.500	2 1/2	4 1/8	4 1/8	6 3/16	6	3
5	141.3	5.563	3	4 7/8	4 7/8	7 5/16	8	3
6	168.3	6.625	3 1/2	5 5/8	5 5/8	8 1/2	8	3 1/2
8	219.1	8.625	4	7	7	10 5/8	8	4
10	273.1	10.750	5	8 1/2	8 1/2	12 3/4	10	5
12	323.9	12.750	6	10	10	15	10	6

ASME B16.9 Monel 400 Concentric & Eccentric Reducer Dimensions

Nominal Pipe Size	Outside Diameter		Reducers
Reduced from (inches)	(mm)	(inches)	Reduced to (inches)	Concentric & Eccentric Length (inches)
1	33.4	1.315	3/8	2
			1/2	2
			3/4	2
1/2	21.3	0.840	1/4	1 1/2
1/2	21.3	0.840	3/8	1 1/2
3/4	26.7	1.050	3/8	2
3/4	26.7	1.050	1/2	2
1 1/4	42.2	1.660	1/2	2
			3/4	2
			1	2
1 1/2	48.3	1.900	1/2	2 1/2
			3/4	2 1/2
			1	2 1/2
			1 1/4	2 1/2
2	60.3	2.375	3/4	3
			1	3
			1 1/4	3
			1 1/2	3
2 1/2	73.0	2.875	1	3 1/2
			1 1/4	3 1/2
			1 1/2	3 1/2
			2	3 1/2
3	88.9	3.500	1	3 1/2
			1 1/2	3 1/2
			2	3 1/2
			2 1/2	3 1/2
3 1/2	101.6	4.000	1 1/4	4
			1 1/2	4
			2	4
			2 1/2	4
			3	4
4	114.3	4.500	1 1/2	4
			2	4
			2 1/2	4
			3	4
			3 1/2	4
5	141.3	5.563	2	5
			2 1/2	5
			3	5
			3 1/2	5
			4	5
6	168.3	6.625	2 1/2	5 1/2
			3	5 1/2
			3 1/2	5 1/2
			4	5 1/2
			5	5 1/2
8	219.1	8.625	3	6
			3 1/2	6
			4	6
			5	6
			6	6
10	273.1	10.750	4	7
			5	7
			6	7
			8	7
12	323.9	12.750	5	8
			6	8
			8	8
			10	8

Monel 400 Buttweld Fittings Weights(Kg)

Product range and theoretical weights (kg)
DN	Schedule 10S			Schedule 40S			Schedule 80S
DN	90° Elbow	45° Elbow	Equal tee	90° Elbow	45° Elbow	Equal tee	90° Elbow	45° Elbow	Equal tee
8	0.02	0.01	0.03	0.03	0.02	0.06	0.04	0.03	0.07
10	0.03	0.02	0.05	0.03	0.02	0.03	0.06	0.04	0.09
15	0.06	0.03	0.09	0.08	0.04	0.10	0.10	0.05	0.14
20	0.07	0.03	0.13	0.08	0.04	0.17	0.11	0.05	0.20
25	0.14	0.08	0.28	0.15	0.11	0.29	0.22	0.14	0.38
32	0.23	0.11	0.49	0.26	0.17	0.59	0.40	0.23	0.68
40	0.30	0.17	0.68	0.40	0.23	0.86	0.51	0.29	1.02
50	0.50	0.25	0.85	0.70	0.4	1.28	0.91	0.59	1.59
65	0.85	0.48	1.41	1.40	0.77	2.19	1.81	0.99	3.13
80	1.25	0.63	1.77	2.20	1.08	3.31	2.97	1.50	4.45
90	1.70	0.75	2.67	2.83	1.42	4.08	4.00	2.00	5.44
100	2.10	1.08	3.46	4.47	2.09	5.27	6.18	2.81	7.71
150	5.45	2.72	8.07	10.89	5.44	10.99	16.32	8.16	13.61
200	10.20	5.33	15.65	21.54	10.77	20.91	33.11	16.96	28.12
250	18.15	9.75	26.46	38.56	19.27	35.38	51.71	25.86	49.90
300	25.80	13.62	39.46	59.42	29.71	62.14	79.38	39.69	83.91

Product range and theoretical weights (kg)
DN	Schedule 10S			Schedule 40S			Schedule 80S
DN	Con reducer	Ecc reducer	Reducing tee	Con reducer	Ecc reducer	Reducing tee	Con reducer	Ecc reducer	Reducing tee
40x.25	0.19	0.19	0.60	0.26	0.26	0.76	0.34	0.34	0.90
50x25	0.28	0.28	0.73	0.40	0.40	1.10	0.54	0.54	1.37
50x40	0.31	0.31	0.76	0.45	0.45	1.15	0.59	0.59	1.43
80x.50	0.55	0.55	1.56	1.00	1.00	2.91	1.79	1.79	3.91
100x50	0.78	0.78	2.94	1.50	1.50	4.48	1.95	1.95	6.55
100x80	0.87	0.87	3.04	1.74	1.74	4.64	2.33	2.33	6.79
150x80	1.82	1.82	6.86	3.95	3.95	9.68	5.51	5.51	11.57
150x100	1.96	1.96	7.10	4.07	4.07	11.94	5.96	5.96	11.97
200x100	3.01	3.01	13.46	6.55	6.55	17.98	9.23	9.23	24.18
200x150	3.19	3.19	14.08	6.74	6.74	18.82	10.12	10.12	25.31

Ready Stock Monel 400 Pipe Fittings

ANSI B16.9 Monel 400 Short Stub End
Monel 400 Pipe Bend In Indonesia
Monel 400 Seamless Fittings In Malaysia
2.4360 Butt weld Fittings
ASME SB366 Monel® Alloy 400 Lateral Tee
Monel JIS NCF 400 Mandrel Pipe Bend In Mexico
ASME B16.9 Schedule 10 Monel® Alloy 400 Elbow
ASME B16.9 Monel 400 Buttweld Fittings
Monel® Alloy 400 Butt weld Tee
Monel 400 Welded Fittings In Philippines
Alloy 400 Eccentric Reducer Manufacturer
Alloy 400 1D Elbow/3D Elbow/5D Elbow
Alloy 400 Reducing Nipple In Japan
400 Monel Buttweld Nipple
Monel® Alloy 400 Lap Joint Stub End
ASTM B366 Monel 400 Buttweld Fittings
Monel® Alloy 400 Pipe Elbow In Italy
Monel 400 Piggable Bends In Spain
ASTM B366 Alloy 400 45 Degree Elbow
UNS N06400 Pipe Fittings
Nickel Alloy 400 End Cap Distributor
Alloy 400 Long Radius Elbow In Singapore
400 Monel 180° LR Return Bends
ASTM B366 Monel 400 Stub End
ANSI B16.9 Monel 400 Pipe Cap
1/2” - 16” ASTM B366 Alloy 400 Butt weld Elbow
SCH 60 Monel® Alloy 400 Pipe Nipples
Monel Alloy 400 Two Joint Pipe Fittings In Kuwait
15 NB SCH 10 Monel 400 90° Short Radius Elbow
Monel 400 SR Elbow
Monel 400 Reducer
Monel® Alloy 400 Elbow
Monel 400 Long Stub End In Spain
Monel Alloy 400 Eccentric Reducer In Italy
Monel 400 Buttweld Fittings In Philippines
Monel 400 Butt Weld Pipe Fittings
Monel Alloy 400 Long Radius Bend Stockholder
Schedule 80 Monel 400 Grade Long Stub End In Mexico
Alloy 400 LR Elbow Stockist
Sch 80 Monel 400 Pipe Fittings
DIN 2605 Monel 400 Elbow Exporter
DIN 2.4360 Swage Nipple
Alloy 400 Barrel Nipple Supplier in Mumbai
ASTM B366 Monel 400 Pipe Fittings
Monel® Alloy 400 Equal Cross
Monel 400 Two Halve Butt weld Fittings In Japan
5" Nb Sch10s Monel 400 90° Short Radius Elbow
Nickel Alloy 400 Pipe Fittings Manufacturer

Monel 400 Butt weld Fittings Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni
Monel 400	0.30 max	2.00 max	0.50 max	0.024 max	28.00 – 34.00	2.50 max	63.00 min

Monel 400 Pipe Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Monel 400	8.8 g/cm3	1350 °C (2460 °F)	Psi – 80,000 , MPa – 550	Psi – 35,000 , MPa – 240	40 %
