Strength of this Inconel Alloy Long Stubend Pipe Fittings is derived from the stiffening impact of molybdenum and niobium on its nickel-chromium matrix; therefore precipitation-hardening remedies aren't required. This mixture of factors is also liable for advanced resistance to a huge variety of corrosive environments of uncommon severity in addition to excessive-temperature outcomes which include oxidation and carburization. Monel Alloy Long Stubend Pipe Fittingsis an excessive-temperature, matrix-stiffened, alloy with brilliant oxidation resistance, and high-quality strength at as much as 2200 Degree F (1200 Degree C). It is used for additives which include combustion chambers, afterburners and tail pipes in plane and land-primarily based totally fueloline turbine engines; for fans, curler hearths and assist participants in business furnaces, and in nuclear engineering.
Hastelloy Alloy Long Stubend Pipe Fittingsis a trendy-cause engineering material for applications that require resistance to warmth and corrosion. A brilliant function is its resistance to excessive- temperature oxidation. The alloy additionally has correct resistance to aqueous corrosion, has excessive mechanical strength, and is without difficulty formed, machined and welded. The alloy's nickel base, together with large chromium content material, gives resistance with many corrosive media and excessive- temperature environments. The properties of Nickel Alloy Long Stubend Pipe Fittings make it a material of extensive application in such fields as thermal processing, chemical processing, pollutants control, aerospace, and strength generation.
Specification Chart of Long & Short Stub Ends
Dimensions |
ASME B16.25, B16.28, MSS-SP-43, ANSI/ASME B16.9 |
Fabricated Size |
1/2" (15 NB) to 48" (1200NB) |
Seamless Size |
1/2"~24" |
Thickness |
5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
Schedule |
SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
Type |
Welded, Seamless, Fabricated |
Material Grades Of Long & Short Stub Ends
Stainless Steel Long & Short Stub Ends |
ASTM A403 WP316, 316L, WP304, 304L, ASTM A182 F316L, 304L, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404 |
Alloy Steel Long & Short Stub Ends |
ASTM A234, ASME SA234 WP1, WP5, WP9, WP11, WP22, WP91 |
Super Duplex Long & Short Stub Ends |
ASTM A815 / ASME SA815 UNS No S32750, S32950 |
Duplex Steel Long & Short Stub Ends |
ASTM A815 / ASME SA815 UNS No S31803, S32205 |
Nickel Alloy Long & Short Stub Ends |
ASTM B336, ASME SB336, Nickel 200 (UNS N02200), Nickel 201 (UNS N02201), Monel 400 (UNS N04400), Monel 500 (UNS N05500), Inconel 800 (UNS N08800), Inconel 825 (UNS N08825), Inconel 600 (UNS N06600), Inconel 625 (UNS N06625), Inconel 601 (UNS N06601), Hastelloy C 276 (UNS N10276), Titanium (Grade I & II), Alloy 20 (UNS N08020), Cupro Nickel 70/30, CuNi30Mn1Fe, CuNi10Fe1Mn. |
Carbon Steel Long & Short Stub Ends |
ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70. |
Low Temperature Carbon Steel Long & Short Stub Ends |
ASTM A420 WPL3, A420 WPL6 |
View Thickness Table Of Long Stub Ends, We have Global sales network for Short Stub Ends, Wide Stockist Of Long Stub Ends, Short Stub Ends In India.
Long Stub Ends Dimensions
Product |
Nom. Pipe Size |
Dia (G) |
Length (F), Short |
Outside Dia (O.D.) |
Sch 160, Inside Dia (I.D.) |
Sch 160, Lap Thickness (t) |
Schedule 160, Wall Thickness (T) |
XX Strong Wall Approx. Weight |
XX Strong Wall, Inside Dia (I.D.) |
1 1/2″ Stubs Ends Long Type “A |
1.5 |
2.875 |
2 |
1.9 |
1.338 |
0.281 |
0.281 |
2.98 |
1.1 |
1 1/2″ Stubs Ends Long Type “A” |
1.5 |
2.875 |
4 |
1.9 |
0.15 |
0.15 |
1.49 |
1.5 |
0.2 |
1 1/4″ Stubs Ends Long Type “A |
1.25 |
2.5 |
2 |
1.66 |
1.16 |
0.25 |
0.25 |
2.52 |
0.896 |
1 1/4″ Stubs Ends Long Types “A” |
1.25 |
2.5 |
4 |
1.66 |
0.14 |
0.14 |
1.26 |
1.278 |
0.191 |
1″ Stubs Ends Long Types “A |
1 |
2 |
2 |
1.315 |
0.815 |
0.25 |
0.25 |
1.76 |
0.599 |
1″ Stubs Ends Long Types “A” |
1 |
2 |
4 |
1.315 |
0.133 |
0.133 |
0.88 |
0.957 |
0.179 |
1/2″ Stubs Ends Long Types “A |
0.5 |
1.375 |
2 |
0.84 |
0.464 |
0.187 |
0.188 |
0.68 |
0.252 |
1/2″ Stubs Ends Long Types “A” |
0.5 |
1.375 |
3 |
0.84 |
0.109 |
0.109 |
0.34 |
0.546 |
0.147 |
10″ Stubs Ends Long Types “A |
10 |
12.75 |
5 |
10.75 |
8.5 |
1.125 |
1.125 |
– |
– |
10″ Stubs Ends Long Types “A” |
10 |
12.75 |
10 |
10.75 |
0.365 |
0.365 |
54 |
9.75 |
0.5 |
12″ Stubs Ends Long Types “A |
12 |
15 |
6 |
12.75 |
10.126 |
1.312 |
1.312 |
– |
– |
12″ Stubs Ends Long Types “A” |
12 |
15 |
10 |
12.75 |
0.375 |
0.375 |
64.5 |
11.75 |
0.5 |
14″ Stubs Ends Long Types “A” |
14 |
16.25 |
12 |
14 |
0.375 |
0.375 |
84 |
13 |
0.5 |
16″ Stubs Ends Long Types “A” |
16 |
18.5 |
12 |
16 |
0.375 |
0.375 |
98 |
15 |
0.5 |
18″ Stubs Ends Long Types “A” |
18 |
21 |
12 |
18 |
0.375 |
0.375 |
136 |
17 |
0.5 |
2 1/2″ Stubs Ends Long Types “A |
2.5 |
4.125 |
2.5 |
2.875 |
2.125 |
0.375 |
0.375 |
8.8 |
1.771 |
2 1/2″ Stubs Ends Long Types “A” |
2.5 |
4.125 |
6 |
2.875 |
0.203 |
0.203 |
4.4 |
2.323 |
0.276 |
2″ Stubs Ends Long Types “A |
2 |
3.625 |
2.5 |
2.375 |
1.689 |
0.343 |
0.343 |
6.1 |
1.503 |
2″ Stubs Ends Long Types “A” |
2 |
3.625 |
6 |
2.375 |
0.154 |
0.154 |
3.05 |
1.939 |
0.218 |
20″ Stubs Ends Long Types “A” |
20 |
23 |
12 |
20 |
0.375 |
0.375 |
157 |
19 |
0.5 |
3 1/2″ Stubs Ends Long Types “A |
3.5 |
5.5 |
3 |
4 |
– |
– |
– |
15.5 |
2.728 |
3 1/2″ Stubs Ends Long Types “A” |
3.5 |
5.5 |
6 |
4 |
0.226 |
0.226 |
7.75 |
3.364 |
0.318 |
3″ Stubs Ends Long Types “A |
3 |
5 |
2.5 |
3.5 |
2.624 |
0.438 |
0.438 |
9.8 |
2.3 |
3″ Stubs Ends Long Types “A” |
3 |
5 |
6 |
3.5 |
0.216 |
0.216 |
6.5 |
2.9 |
0.3 |
3/4″ Stubs Ends Long Types “A |
0.75 |
1.688 |
2 |
1.05 |
0.612 |
0.218 |
0.219 |
0.94 |
0.434 |
3/4″ Stubs Ends Long Types “A” |
0.75 |
1.688 |
3 |
1.05 |
0.113 |
0.113 |
0.47 |
0.742 |
0.154 |
4″ Stubs Ends Long Types “A |
4 |
6.188 |
3 |
4.5 |
3.438 |
0.531 |
0.531 |
19.3 |
3.152 |
4″ Stubs Ends Long Types “A” |
4 |
6.188 |
6 |
4.5 |
0.237 |
0.237 |
9.65 |
3.826 |
0.337 |
5″ Stubs Ends Long Types “A |
5 |
7.313 |
3 |
5.563 |
4.313 |
0.625 |
0.625 |
32.66 |
4.063 |
5″ Stubs Ends Long Types “A” |
5 |
7.313 |
8 |
5.563 |
0.258 |
0.258 |
16.33 |
4.813 |
0.375 |
6″ Stubs Ends Long Types “A |
6 |
8.5 |
3.5 |
6.625 |
5.187 |
0.718 |
0.719 |
45.26 |
4.897 |
6″ Stubs Ends Long Types “A” |
6 |
8.5 |
8 |
6.625 |
0.28 |
0.28 |
22.63 |
5.761 |
0.432 |
8″ Stubs Ends Long Types “A |
8 |
10.625 |
4 |
8.625 |
6.813 |
0.906 |
0.906 |
59.71 |
6.875 |
8″ Stubs Ends Long Types “A” |
8 |
10.625 |
8 |
8.625 |
0.322 |
0.322 |
34.12 |
7.625 |
0.5 |
Short Stub Ends Dimensions
Product |
Nom. Pipe Size |
Diameter (G) |
Length (J) |
Outside Diameter (O.D.) |
Schedule 5S Approx. Weight |
Schedule 5S, Inside Diameter (I.D.) |
Schedule 5S, Wall Thickness (T) |
1 1/2″ Short Stubs Ends Short Type “C” |
1.5 |
2.875 |
2 |
1.9 |
0.29 |
1.77 |
0.065 |
1 1/4″ Short Stubs Ends Short Type “C” |
1.25 |
2.5 |
2 |
1.66 |
0.21 |
1.53 |
0.065 |
1″ Short Stubs Ends Short Type “C” |
1 |
2 |
2 |
1.315 |
0.19 |
1.185 |
0.065 |
1/2″ Short Stubs Ends Short Type “C” |
0.5 |
1.375 |
2 |
0.84 |
0.13 |
0.71 |
0.065 |
10″ Short Stubs Ends Short Type “C” |
10 |
12.75 |
5 |
10.75 |
7.48 |
10.482 |
0.134 |
12″ Short Stubs Ends Short Type “C” |
12 |
15 |
6 |
12.75 |
15 |
12.438 |
0.156 |
14″ Short Stubs Ends Short Type “C” |
14 |
16.25 |
6 |
14 |
19.2 |
13.688 |
0.156 |
16″ Short Stubs Ends Short Type “C” |
16 |
18.5 |
6 |
16 |
23.9 |
15.67 |
0.165 |
18″ Short Stubs Ends Short Type “C” |
18 |
21 |
6 |
18 |
28.5 |
17.67 |
0.165 |
2 1/2″ Short Stubs Ends Short Type “C” |
2.5 |
4.125 |
2.5 |
2.875 |
0.75 |
2.709 |
0.083 |
2″ Short Stubs Ends Short Type “C” |
2 |
3.625 |
2.5 |
2.375 |
0.44 |
2.245 |
0.065 |
20″ Short Stubs Ends Short Type “C” |
20 |
23 |
6 |
20 |
36.3 |
19.624 |
0.188 |
24″ Short Stubs Ends Short Type “C” |
24 |
27.25 |
6 |
24 |
56 |
23.564 |
0.218 |
3″ Short Stubs Ends Short Type “C” |
3 |
5 |
2.5 |
3.5 |
0.94 |
3.334 |
0.083 |
3/4″ Short Stubs Ends Short Type “C” |
0.75 |
1.688 |
2 |
1.05 |
0.14 |
0.92 |
0.065 |
4″ Short Stubs Ends Short Type “C” |
4 |
6.188 |
3 |
4.5 |
1.38 |
4.334 |
0.083 |
5″ Short Stubs Ends Short Type “C” |
5 |
7.313 |
3 |
5.563 |
2.06 |
5.345 |
0.109 |
6″ Short Stubs Ends Short Type “C” |
6 |
8.5 |
3.5 |
6.625 |
2.75 |
6.407 |
0.109 |
8″ Short Stubs Ends Short Type “C” |
8 |
10.625 |
4 |
8.625 |
3.88 |
8.407 |
0.109 |
Check available Sizes of Long Stub Ends, Ask For Ready Stock of Long Stub Ends. Stub Ends in Mumbai, India.
