Stainless Steel Concentric Reducer Pipe Fittings is utilized in chemical and petrochemical processing, in electricity vegetation for super-heater and reheater tubing, in business furnaces, and for warmth treating equipment. It is an alloy with additions of molybdenum and titanium. The titanium and aluminum additions purpose a powering response at some point of warmness remedy. It is utilized in numerous applications requiring a mixture of excessive power and corrosion resistance.
Molybdenum additionally imparts resistance to localized attack (pitting and crevice corrosion). Because of the alloy’s resistance to sulfide pressure cracking and pressure-corrosion cracking in “sour” (H2S containing) crude oil and herbal fueloline, it's far used for down-hollow and floor gaswell additives which includes tubular products, valves, hangers, touchdown nipples, device joints and packers. Carbon Steel Concentric Reducer Pipe Fittings is likewise beneficial for fasteners, marine and pump shafting and excessive-power piping systems.
Specification Chart of Concentric Reducer
Dimensions |
ASME B16.25, B16.28, MSS-SP-43, ANSI/ASME B16.9 |
Fabricated Size |
1/2" (15 NB) to 48" (1200NB) |
Seamless Size |
1/2"~24" |
Thickness |
5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
Schedule |
SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
Type |
Welded, Seamless, Fabricated |
Material Grades Of Concentric Reducer
Stainless Steel Concentric Reducer |
ASTM A403 WP316, 316L, WP304, 304L, ASTM A182 F316L, 304L, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404 |
Alloy Steel Concentric Reducer |
ASTM A234, ASME SA234 WP1, WP5, WP9, WP11, WP22, WP91 |
Super Duplex Concentric Reducer |
ASTM A815 / ASME SA815 UNS No S32750, S32950 |
Duplex Steel Concentric Reducer |
ASTM A815 / ASME SA815 UNS No S31803, S32205 |
Nickel Alloy Concentric Reducer |
ASTM B336, ASME SB336, Nickel 200 (UNS N02200), Nickel 201 (UNS N02201), Monel 400 (UNS N04400), Monel 500 (UNS N05500), Inconel 800 (UNS N08800), Inconel 825 (UNS N08825), Inconel 600 (UNS N06600), Inconel 625 (UNS N06625), Inconel 601 (UNS N06601), Hastelloy C 276 (UNS N10276), Titanium (Grade I & II), Alloy 20 (UNS N08020), Cupro Nickel 70/30, CuNi30Mn1Fe, CuNi10Fe1Mn. |
Carbon Steel Concentric Reducer |
ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70. |
Low Temperature Carbon Steel Concentric Reducer |
ASTM A420 WPL3, A420 WPL6 |
View Thickness Table Of Welded Concentric Reducer, We have Global sales network for Buttweld Reducer, Wide Stockist Of Concentric Pipe Reducer, Buttweld Reducer In India.
Concentric Reducer Dimensions
REDUCERS |
inches |
mm |
D |
d |
H |
3/4 x 3/4 |
20 x 15 |
26,67 |
21,34 |
38,10 |
3/4 x 3/8 |
20 x 10 |
26,67 |
17,14 |
38,10 |
1 x 3/4 |
25 x 20 |
33,40 |
26,67 |
50,80 |
1 x 1/2 |
25 x 15 |
33,40 |
21,34 |
50,80 |
1 1/4 x 1 |
32 x 25 |
42,16 |
33,40 |
50,80 |
1 1/4 x 3/4 |
32 x 20 |
42,16 |
26,67 |
50,80 |
1 1/4 x 1/2 |
32 x 15 |
42,16 |
21,34 |
50,80 |
1 1/2 x 1 1/4 |
40 x 32 |
48,26 |
42,16 |
63,50 |
1 1/2 x 1 |
40 x 25 |
48,26 |
33,40 |
63,50 |
1 1/2 x 3/4 |
40 x 20 |
48,26 |
26,67 |
63,50 |
1 1/2 x 1/2 |
40 x 15 |
48,26 |
21,34 |
63,50 |
2 x 1 1/2 |
50 x 40 |
60,32 |
48,26 |
76,20 |
2 x 1 1/4 |
50 x 32 |
60,32 |
42,16 |
76,20 |
2 x 1 |
50 x 25 |
60,32 |
33,40 |
76,20 |
2 x 3/4 |
50 x 20 |
60,32 |
26,67 |
76,20 |
2 1/2 x 2 |
65 x 50 |
73,02 |
60,32 |
88,90 |
2 1/2 x 1 1/2 |
65 x 40 |
73,02 |
48,26 |
88,90 |
2 1/2 x 1 1/4 |
65 x 32 |
73,02 |
42,16 |
88,90 |
2 1/2 x1 |
65 x 25 |
73,02 |
33,40 |
88,90 |
3 x 2 1/2 |
80 x 65 |
88,90 |
73,02 |
88,90 |
3 x 2 |
80 x 50 |
88,90 |
60,32 |
88,90 |
3 x 1 1/2 |
80 x 40 |
88,90 |
48,26 |
88,90 |
3 x 1 1/4 |
80 x 32 |
88,90 |
42,16 |
88,90 |
3 1/2 x 3 |
90 x 80 |
101,60 |
88,90 |
101.60 |
3 1/2 x 2 1/2 |
90 x 65 |
101,60 |
73,02 |
101.60 |
3 1/2 x 2 |
90 x 50 |
101,60 |
60,32 |
101.60 |
3 1/2 x 1 1/2 |
90 x 40 |
101,60 |
48,26 |
101.60 |
3 1/2 x 1 1/4 |
90 x 32 |
101,60 |
42,16 |
101.60 |
4 x 3 1/2 |
100 x 90 |
114,30 |
73,02 |
101.60 |
4 x 3 |
100 x 80 |
114,30 |
88,90 |
101.60 |
4 x 2 1/2 |
100 x 65 |
114,30 |
73,02 |
101.60 |
4 x 2 |
100 x 50 |
114,30 |
60,32 |
101.60 |
4 x 1 1/2 |
100 x 40 |
114,30 |
48,26 |
101.60 |
5 x 4 |
125 x 100 |
141,30 |
114,30 |
127,00 |
5 x 3 1/2 |
125 x 90 |
141,30 |
101,60 |
127,00 |
5 x 3 |
125 x 80 |
141,30 |
88,90 |
127,00 |
5 x 2 1/2 |
125 x 65 |
141,30 |
73,02 |
127,00 |
5 x 2 |
125 x 50 |
141,30 |
60,32 |
127,00 |
6 x 5 |
150 x 125 |
168,27 |
141,30 |
139,7 |
6 x 4 |
150 x 100 |
168,27 |
114,30 |
139,7 |
6 x 1/2 |
150 x 90 |
168,27 |
101,60 |
139,7 |
6 x 3 |
150 x 80 |
168,27 |
88,90 |
139,7 |
6 x 1/2 |
150 x 65 |
168,27 |
73,02 |
139,7 |
8 x 6 |
200 x 150 |
219,07 |
168,27 |
152,4 |
8 x 5 |
200 x 125 |
219,07 |
141,30 |
152,4 |
8 x 4 |
200 x 100 |
219,07 |
114,30 |
152,4 |
8 x 3 1/2 |
200 x 90 |
219,07 |
101,60 |
152,4 |
10 x 8 |
250 x 200 |
273,05 |
219,07 |
177,8 |
10 x 6 |
250 x 150 |
273,05 |
168,27 |
177,8 |
10 x 5 |
250 x 125 |
273,05 |
141,30 |
177,8 |
10 x 4 |
250 x 100 |
273,05 |
114,30 |
177,8 |
12 x 10 |
300 x 250 |
323,85 |
273,05 |
203,2 |
12 x 8 |
300 x 200 |
323,85 |
219,07 |
203,2 |
12 x 6 |
300 x 150 |
323,85 |
168,27 |
203,2 |
12 x 5 |
300 x 125 |
323,85 |
141,30 |
203,2 |
14 x 12 |
350 x 300 |
355,60 |
323,85 |
330,2 |
14 x 10 |
350 x 250 |
355,60 |
273,05 |
330,2 |
14 x 8 |
350 x 200 |
355,60 |
219,07 |
330,2 |
14 x 6 |
350 x 150 |
355,60 |
168,27 |
330,2 |
16 x 14 |
400 x 350 |
406,40 |
355,60 |
355,6 |
16 x 12 |
400 x 300 |
406,40 |
323,85 |
355,6 |
16 x 10 |
400 x 250 |
406,40 |
273,05 |
355,6 |
16 x 8 |
400 x 200 |
406,40 |
219,07 |
355,6 |
18 x 16 |
450 x 400 |
457,20 |
406,40 |
381,0 |
18 x 14 |
450 x 350 |
457,20 |
355,60 |
381,0 |
18 x 12 |
450 x 300 |
457,20 |
323,85 |
381,0 |
18 x 10 |
450 x 250 |
457,20 |
273,05 |
381,0 |
20 x 18 |
500 x 450 |
508,00 |
457,20 |
508,0 |
20 x 16 |
500 x 400 |
508,00 |
406,40 |
508,0 |
20 x 14 |
500 x 350 |
508,00 |
355,60 |
508,0 |
20 x 12 |
500 x 300 |
508,00 |
323,85 |
508,0 |
22 x 20 |
550 x 500 |
558,80 |
508,00 |
508,0 |
22 x 18 |
550 x 450 |
558,80 |
457,20 |
508,0 |
22 x 16 |
550 x 400 |
558,80 |
406,40 |
508,0 |
22 x 14 |
550 x 350 |
558,80 |
355,60 |
508,0 |
24 x 22 |
600 x 550 |
609,6 |
558,80 |
508,0 |
24 x 20 |
600 x 500 |
609,6 |
508,00 |
508,0 |
24 x 18 |
600 x 450 |
609,6 |
457,20 |
508,0 |
24 x 16 |
600 x 400 |
609,6 |
406,40 |
508,0 |
Check available Sizes of Concentric Reducer, Ask For Ready Stock of Concentric Pipe Reducer, Welded Concentric Reducer. Concentric Reducer in Mumbai, India.
