LTCS A350 LF2 Long Weld Neck Flanges Stockist, ASTM A350 LF2 SORF Flanges, ASME SA350 LTCS LF2 Forged Flanges, LTCS LF2 RTJ Flanges Supplier in Mumbai, India.
Molybdenum and tungsten content in ASTM A350 LTCS LF2 Long Weld Neck Flanges enhance widespread and localized corrosion resistance properties. The former is a ferrite stabilizer and hence, whilst utilized in austenitic alloys, ought to be balanced with austenite stabilizers to keep austenite composition. Molybdenum additionally complements excessive-temperature strength whilst brought to martensitic steel. Adding tungsten with molybdenum additionally improves the above-mentioned properties. Manganese improves the properties of strength, sturdiness and hardenability in steel. The addition of manganese allows the steel carry out higher in hot working processes. Manganese additionally promotes the answer of nitrogen in steel and can also additionally, therefore, be brought to update nickel in steel with nitrogen.
ASME SA 350 LTCS LF2 Ring Type Joint Flanges does now no longer corrode easily, endures hard environments higher and has an extended carrier life. But it isn't absolutely actual that it's miles stain-proof. However, peculiar surrounding situations consisting of low-oxygen, bad movement and excessive salinity can also additionally stain it irreversibly. Despite the above risks, it is a wonder material and has a particularly wonderful effect at the enterprise as a whole. For carbon steels, there's no minimal precise content material of different alloying factors; however, they regularly incorporate manganese. They cannot be hardened with the aid of using warmness remedy (to shape martensitic) so that is generally done with the aid of using cold work.
Material Specification Chart of LTCS A350 LF2 Flanges
| Size Chart | 1/2" (15 NB) to 48" (1200NB) DN10~DN5000 |
|---|---|
| Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Pressure Rating | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Most common types | Forged / Threaded / Screwed / Plate |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. B.S: BS4504 , BS3293, BS1560, BS10 The other standard: AWWA C207; EN1092-1, GOST12820, JIS B2220; KS B1503, SABS1123; NFE29203; UNI2276 |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
LTCS A350 LF2 Flanges Manufacturing Standards
| American Standard | Standard Code | ANSI ASME SA350 | ANSI ASME B16.5 | ASME – B 16.47 | ASME – B 16.36 | ||
|---|---|---|---|---|---|---|---|
| Standard Name | Forged Flanges | Slip on flange, Welding neck flange, Blind flange, Threaded flange, Lap joint flange, RTJ flange | Welding neck flange, Blind flange | Welding neck flange Slip on flange | |||
| German Standard | DIN 2527 | DIN 2573 / 2576 | DIN 2673 | DIN 2641 / 2642 | DIN 28115 | DIN PN10, PN16 | DIN PN20, PN25 |
| Blind Flanges, BLRF | Flat Flange for Welding (Slip On) | Loose Flanges and Rings for Welding (Slip On Flanges and Plain Collars) | Lapped / Loose (Lap Joint) Flanges Plain Collars | Long Neck Welding Flanges | PN10 Flanges, DIN PN 10 Flanges, PN16 Flange | PN20 Flanges, DIN PN 25 Flanges | |
| Japanese Standard | JIS B2220 | JIS B2291 | JIS 5K, 10K | JIS 16K, 20K | JIS 30K, 40K | ||
| Slipon plate flange (SOP), Slipon Hub (SOH), Socket Welding flange (SW), Welding neck flange (WN), Lapjoint (LJ), Threaded flange (TR)/ Itegral flange (IT) Blank flange (BL) | Slipon plate flange (SOP), Slipon Hub (SOH), Socket Welding flange (SW), Welding neck flange (WN), Lapjoint (LJ), Threaded flange (TR)/ Itegral flange (IT) Blank flange (BL) | 5K SORF Flanges, 10K SOFF Flanges | 16K Blind Flanges, 20K BLRF Flanges | 30K Slip on Flanges, 40K Blind Flanges | |||
| Italian Standard | UNI FLANGES | ||||||
| Plan flanges (2276, 2277, 2278, 6083, 6084) Welding neck (2280, 2281, 2282, 2283, 2284, 2285, 2286) Lapped flanges (6088, 6089, 6090, 2999, 2300) Blind flanges (6091, 6092, 6093, 6094, 6095, 6096, 6097) threaded flanges (2253, 2254) | |||||||
| British Standard | BS 10 Table D | BS 10 Table E | BS 10 Table F | BS 10 Table H | |||
| BS 10 Table D Flanges, Table D Pipe Flange | BS 10 Table E Flanges, Table E Pipe Flange | BS 10 Table E Flanges, Table E Flanges | BS 10 Table E Flanges, Table E Pipe Flanges |
Manufacturing Standards / Pressure Rating
| ASME/ANSI B 16.5 | Blind Flange, High Hub Blind Flange, Slip on Flange, Welding Neck Flange, Socket Weld Flange, Ring Type Joint Flange, Lap Joint Flange, Threaded Flange |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| ASME/ANSI B 16.47 | Blind Flange [Series A & B],Welding Neck Flange |
| PRESSURE CLASS | 75, 150, 300, 400, 600, 900 |
| ASME/ANSI B 16.36 | Slip on Flange, Threaded Flange, Welding Neck Flange, |
| PRESSURE CLASS | 300, 400, 600, 900, 1500, 2500 |
| BS 4504 SEC 3.1 | Plate Flange, Loose Plate Flange, Loose Plate With Weld Neck Flange, Blank Flange, Welding Neck Flange, Hubbed Slip on Flange, Hubbed Threaded Flange, Lapped Pipe End Flange, |
| PRESSURE CLASS | PN 2.5 TO PN 40 |
| BS 4504[PART 1] | Plate Flange, Loose Plate With Weld On Plate Collar, Blank Flange, Welding Neck Flange, Hubbed Slip-On Hubbed Threaded, |
| PRESSURE CLASS | PN 2.5 TO PN A350 |
| BS 1560 BOSS | Plate Flange, Loose Plate With Weld On Plate Collar, Blank Flange, Welding Neck Flange, Hubbed Slip-On Hubbed Threaded, |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| BS10 | Welding Neck Flange, Plate Slip-On Flange, Screwed Boss Flange, Slip-On Boss Flange, Blind Flange |
| TABLE | D, E, F, H |
| DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| PRESSURE CLASS | PN 6 TO PN 100 |
Various Types Of LTCS A350 LF2 Flanges
- ASTM A350 LTCS LF2 Socket weld Flanges
- LTCS A350 LF2 SWRF Flanges
- Low Temperature Carbon Steel LF2 Socket weld Flange
- LTCS A350 LF2 Socket weld Flanges
- ASME SA350 LTCS LF2 SWRF Flanges
- Low Temperature LF2 Socket weld Flanges
- LTCS A350 LF2 LJ Flanges
- LTCS A350 LF2 Lapped Joint Flanges
- Low Temperature LF2 Lap Joint Flanges
- ASTM A350 Low Temperature LF2 Lap Joint Flanges
- Low Temperature Carbon Steel LF2 Lap Joint Flange
- ASME SA350 LTCS LF2 Lapped Joint Flanges
- LTCS A350 LF2 Slip on Flange
- Low Temperature LF2 SORF Flanges
- ASTM A350 LF2 Slip on Flanges
- Low Temperature LF2 Slip on Flanges
- Low Temperature Carbon Steel LF2 Slip on Flanges
- ASME SA350 LTCS LF2 SORF Flanges
- ASME SA350 LTCS LF2 Forged Flanges
- LTCS LF2 Forged Flange
- Low Temperature LF2 Forged Flanges
- Low Temperature Carbon Steel LF2 Forged Flanges
- Low Temperature CS LF2 Forged Flanges
- ASTM A350 LTCS LF2 Forged Flanges
- LTCS LF2 Orifice Flange
- Low Temperature LF2 Orifice Flanges
- Low Temperature CS LF2 Orifice Flanges
- ASTM A350 LTCS LF2 Orifice Flanges
- Low Temperature CS LF2 Orifice Flanges
- ASME SA350 LTCS LF2 Orifice Flanges
- ASME SA350 LTCS LF2 BLRF Flanges
- LTCS LF2 Blind Flanges
- Low Temperature LF2 BLRF Flanges
- Low Temperature CS LF2 Blind Flange
- ASTM A350 LTCS LF2 Blind Flanges
- Low Temperature Carbon Steel LF2 Blind Flanges
- ASME SA350 LTCS LF2 WNRF Flanges
- LTCS LF2 Welding Neck Flanges
- ASTM A350 LTCS LF2 Weld Neck Flanges
- Low Temperature LF2 Welding Neck Flange
- LTCS LF2 WNRF Flanges
- Low Temperature CS LF2 Weld Neck Flanges
- ASME SA350 LTCS LF2 Reducing Flanges
- ASTM A350 LF2 Reducing Flanges
- Low Temperature LF2 Reducing Flanges
- LTCS LF2 Reducing Flanges
- Low Temperature LF2 Reducing Flange
- Low Temperature CS LF2 Reducing Flanges
- LTCS LF2 Screwed Flanges
- Low Temperature LF2 Threaded Flanges
- ASTM A350 LF2 Threaded Flanges
- ASME SA350 LTCS LF2 Screwed Flanges
- Low Temperature CS LF2 Threaded Flanges
- A350 LF2 Low Temperature Threaded Flange
- LTCS LF2 Long Weld Neck Flange
- ASME SA350 LTCS LF2 LWN Flanges
- Low Temperature LF2 Long Weld Neck Flanges
- ASTM A350 LTCS LF2 Long Weld Neck Flanges
- Low Temperature A350 LF2 LWN Flanges
- Low Temperature CS LF2 Long Weld Neck Flanges
- LTCS LF2 Spectacle Blind Flange
- LTCS A350 LF2 Spectacle Blind Flanges
- Low Temperature LF2 Spectacle Blind Flanges
- ASME SA350 LTCS LF2 Spectacle Blind Flanges
- ASTM A350 LTCS LF2 Spectacle Blind Flanges
- Low Temperature CS LF2 Spectacle Blind Flanges
- LTCS A350 LF2 RTJ Flanges
- ASME SA350 LTCS LF2 RTJ Flanges
- LTCS A350 LF2 Ring Type Joint Flange
- ASTM A350 Low Temperature LF2 RTJ Flanges
- Low Temperature CS LF2 Ring Type Joint Flanges
- LTCS LF2 Ring Type Joint Flanges
View Size Table Of LTCS A350 LF2 Pipe Flanges, We have Global sales network for LTCS A350 LF2 SORF Flanges, Wide Stockist Of Low Temperature A350 LF2 BLRF Flanges, Raised Face, Flat Face Flanges In India.
Check available Sizes of ASME SA350 LTCS LF2 Pipe Flanges, Ask For Ready Stock of LTCS A350 LF2 Male & Female Flanges in Mumbai, India.
BAGODA
Quick Contact
Schedule / Class of LTCS A350 LF2 Flanges
| Flange Schedule/Class | Flange Connection Type | Pipe Size – Pipe Flanges | Max. Pressure |
|---|---|---|---|
| ASME B16.5 Class 150 | FNPT | 1/2″ | 150 psi |
| ASME B16.5 Class 150 | Socket Weld | 1/2″ | 275 psi |
| ASME B16.5 Class 150 | Welded | 1/2″ | 150 psi |
| ASME B16.5 Class 150 | FNPT | 3/4″ | 150 psi |
| ASME B16.5 Class 150 | Socket Weld | 3/4″ | 275 psi |
| ASME B16.5 Class 150 | Socket Weld | 1-1/4″ | 275 psi |
| ASME B16.5 Class 150 | Socket Weld | 1-1/2″ | 275 psi |
| ASME B16.5 Class 150 | FNPT | 2″ | 150 psi |
| ASME B16.5 Class 150 | Socket Weld | 2″ | 275 psi |
| ASME B16.5 Class 150 | Socket Weld | 2-1/2″ | 275 psi |
| ASME B16.5 Class 150 | Socket Weld | 3″ | 275 psi |
| ASME B16.5 Class 150 | FNPT | 4″ | 150 psi |
| ASME B16.5 Class 150 | Socket Weld | 4″ | 275 psi |
| ASME B16.5 Class 300 | Slip On | 1/2″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 1/2″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 1″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 1″ | 720 psi |
| ASME B16.5 Class 300 | FNPT | 1-1/4″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 1-1/4″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 1-1/2″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 1-1/2″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 2″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 2″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 2-1/2″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 2-1/2″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 3″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 3″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 4″ | 720 psi |
| ASME B16.5 Class 300 | Slip On | 4″ | 720 psi |
Pressure Rating Of LTCS A350 LF2 Flanges
| ANSI/ASME B16.34 | PRESSURE RATING CHART | ||||||
| Temperature °F | 150# | 300# | 400# | 600# | 900# | 1500# | 2500# |
| -20 to 100 | 275 | 720 | 960 | 1440 | 2160 | 3600 | 6000 |
| 200 | 230 | 600 | 800 | 1200 | 1800 | 3000 | 5000 |
| 300 | 205 | 540 | 720 | 1080 | 1620 | 2700 | 4500 |
| 400 | 190 | 495 | 660 | 995 | 1490 | 2485 | 4140 |
| 500 | 170 | 465 | 620 | 930 | 1395 | 2330 | 3880 |
| 600 | 140 | 435 | 580 | 875 | 1310 | 2185 | 3640 |
| 650 | 125 | 430 | 575 | 860 | 1290 | 2150 | 3580 |
| 700 | 110 | 425 | 565 | 850 | 1275 | 2125 | 3540 |
| 750 | 95 | 415 | 555 | 830 | 1245 | 2075 | 3460 |
| 800 | 80 | 405 | 540 | 805 | 1210 | 2015 | 3360 |
| 850 | 65 | 395 | 530 | 790 | 1190 | 1980 | 3300 |
| 900 | 50 | 390 | 520 | 780 | 1165 | 1945 | 3240 |
| 950 | 35 | 380 | 510 | 765 | 1145 | 1910 | 3180 |
| 1000 | 20 | 320 | 430 | 640 | 965 | 1605 | 2675 |
| 1050 | 20 | 310 | 410 | 615 | 925 | 1545 | 2570 |
| 1100 | 20 | 255 | 345 | 515 | 770 | 1285 | 2145 |
| 1150 | 20 | 200 | 265 | 400 | 595 | 995 | 1655 |
| 1200 | 20 | 155 | 205 | 310 | 465 | 770 | 1285 |
| 1250 | 20 | 115 | 150 | 225 | 340 | 565 | 945 |
| 1300 | 20 | 85 | 115 | 170 | 255 | 430 | 715 |
| 1350 | 20 | 60 | 80 | 125 | 185 | 310 | 515 |
| 1400 | 20 | 50 | 65 | 95 | 145 | 240 | 400 |
| 1450 | 15 | 35 | 45 | 70 | 105 | 170 | 285 |
| 1500 | 10 | 25 | 35 | 55 | 80 | 135 | 230 |
Size Chart Of LTCS A350 LF2 Flange
| Nominal Pipe Size | Outside Diameter of Flanges | Thickness of Flanges | Diameter of Raised Face | Diameter of Hub at Base | Length Thru Hub | Diameter or Bore | Diameter of Hub at Bevel | Radius of Fillet | Depth of Socket | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Welding Neck | Slip-On Threaded Socket | Lap Joint | Slip-on Socket | Lap Joint | ||||||||
| O | Q | R | X | Y | Y | Y | W | B | H | r | Z | |
| 1/2 | 3-1/2 | 7/16 | 1-3/8 | 1-3/16 | 1-7/8 | 5/8 | 5/8 | .88 | .90 | .84 | 1/8 | 3/8 |
| 3/4 | 3-7/8 | 1/2 | 1-11/16 | 1-1/2 | 2-1/16 | 5/8 | 5/8 | 1.09 | 1.11 | 1.05 | 1/8 | 7/16 |
| 1 | 4-1/4 | 9/16 | 2 | 1-15/16 | 2-3/16 | 11/16 | 11/16 | 1.36 | 1.38 | 1.32 | 1/8 | 1/2 |
| 1-1/4 | 4-5/8 | 5/8 | 2-1/2 | 2-5/16 | 2-1/4 | 13/16 | 13/16 | 1.70 | 1.72 | 1.66 | 3/16 | 9/16 |
| 1-1/2 | 5 | 11/16 | 2-7/8 | 2-9/16 | 2-7/16 | 7/8 | 7/8 | 1.95 | 1.97 | 1.90 | 1/4 | 5/8 |
| 2 | 6 | 3/4 | 3-5/8 | 3-1/16 | 2-1/2 | 1 | 1 | 2.44 | 2.46 | 2.38 | 5/16 | 11/16 |
| 2-1/2 | 7 | 7/8 | 4-1/8 | 3-9/16 | 2-3/4 | 1-1/8 | 1-1/8 | 2.94 | 2.97 | 2.88 | 5/16 | 3/4 |
| 3 | 7-1/2 | 15/16 | 5 | 4-1/4 | 2-3/4 | 1-3/16 | 1-3/16 | 3.57 | 3.60 | 3.50 | 3/8 | 13/16 |
| 3-1/2 | 8-1/2 | 15/16 | 5-1/2 | 4-13/16 | 2-13/16 | 1-1/4 | 1-1/4 | 4.07 | 4.10 | 4.00 | 3/8 | 7/8 |
| 4 | 9 | 15/16 | 6-3/16 | 5-5/16 | 3 | 1-5/16 | 1-5/16 | 4.57 | 4.60 | 4.50 | 7/16 | 15/16 |
| 5 | 10 | 15/16 | 7.5/16 | 6-7/16 | 3-1/2 | 1-7/16 | 1-7/16 | 5.66 | 5.69 | 5.56 | 7/16 | 15/16 |
| 6 | 11 | 1 | 8-1/2 | 7-9/16 | 3-1/2 | 1-9/16 | 1-9/16 | 6.72 | 6.75 | 6.63 | 1/2 | 1-1/16 |
| 8 | 13-1/2 | 1-1/8 | 10-5/8 | 9-11/16 | 4 | 1-3/4 | 1-3/4 | 8.72 | 8.75 | 8.63 | 1/2 | 1-1/4 |
| 10 | 16 | 1-3/16 | 12-3/4 | 12 | 4 | 1-15/16 | 1-15/16 | 10.88 | 10.92 | 10.75 | 1/2 | 1-5/16 |
| 12 | 19 | 1-1/4 | 15 | 14-3/8 | 4-1/2 | 2-3/16 | 2-3/16 | 12.88 | 12.92 | 12.75 | 1/2 | 1-9/16 |
| 14 | 21 | 1-3/8 | 16-1/4 | 15-3/4 | 5 | 2-1/4 | 3-1/8 | 14.14 | 14.18 | 14.00 | 1/2 | 1-5/8 |
| 16 | 23-1/2 | 1-7/16 | 18-1/2 | 18 | 5 | 2-1/2 | 3-7/16 | 16.16 | 16.19 | 16.00 | 1/2 | 1-3/4 |
| 18 | 25 | 1-9/16 | 21 | 19-7/8 | 5-1/2 | 2-11/16 | 3-13/16 | 18.18 | 18.20 | 18.00 | 1/2 | 1-15/16 |
| 20 | 27-1/2 | 1-11/16 | 23 | 22 | 5-11/16 | 2-7/8 | 4-1/16 | 20.20 | 20.25 | 20.00 | 1/2 | 2-1/8 |
| 24 | 32 | 1-7/8 | 27-1/4 | 26-1/8 | 6 | 3-1/4 | 4-3/8 | 24.25 | 24.25 | 24.00 | 1/2 | 2-1/2 |
Weight Chart Of LTCS A350 LF2 Flanges
| Pipe Normal Diam. | O.D. Flange | Thk. Of Flange Min | Diam. of Hub |
Diameter of Raised Face | Length Hub.Y | Thread Length | Diam. of Bolt Circle |
Diam. of Bolt Holes |
Number of Bolts |
Diam. of Bolts (inch) |
KG | LB | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| inch | dn | O | C | X | G | Y | T | BC | BH | BN | BD | ||
| 1/2" | 15 | 89.00 | 11.20 | 30.20 | 35.10 | 15.70 | 15.70 | 60.50 | 15.80 | 4 | 1/2" | 0.4 | 0.9 |
| 3/4" | 20 | 98.50 | 12.70 | 38.10 | 42.90 | 15.70 | 15.70 | 69.90 | 15.80 | 4 | 1/2" | 0.7 | 1.5 |
| 1" | 25 | 108.00 | 14.20 | 49.30 | 50.80 | 17.50 | 17.50 | 79.30 | 15.80 | 4 | 1/2" | 0.8 | 1.8 |
| 1-1/4" | 32 | 117.50 | 15.70 | 58.70 | 63.50 | 20.60 | 20.60 | 88.90 | 15.80 | 4 | 1/2" | 1.2 | 2.6 |
| 1-1/2" | 40 | 127.00 | 17.50 | 65.00 | 73.20 | 22.40 | 22.40 | 98.60 | 15.80 | 4 | 1/2" | 1.5 | 3.3 |
| 2" | 50 | 152.50 | 19.10 | 77.70 | 91.90 | 25.40 | 25.40 | 120.70 | 19.10 | 4 | 5/8" | 2.3 | 5.1 |
| 2-1/2" | 65 | 178.00 | 22.40 | 90.40 | 104.60 | 28.40 | 28.40 | 139.70 | 19.10 | 4 | 5/8" | 3.7 | 8.1 |
| 3" | 80 | 190.50 | 23.90 | 108.00 | 127.00 | 30.20 | 30.20 | 152.40 | 19.10 | 4 | 5/8" | 4.1 | 9 |
| 3-1/2" | 90 | 216.00 | 23.90 | 122.20 | 139.70 | 31.80 | 31.80 | 177.80 | 19.10 | 8 | 5/8" | 5.1 | 11.2 |
| 4" | 100 | 228.50 | 23.90 | 134.90 | 157.20 | 33.30 | 33.30 | 190.50 | 19.10 | 8 | 5/8" | 5.9 | 13 |
| 5" | 125 | 254.00 | 23.90 | 163.60 | 185.70 | 36.60 | 36.60 | 215.90 | 22.40 | 8 | 3/4" | 7 | 15.4 |
| 6" | 150 | 279.50 | 25.40 | 192.00 | 215.90 | 39.60 | 39.60 | 241.30 | 22.40 | 8 | 3/4" | 8.4 | 18.5 |
| 8" | 200 | 343.00 | 28.40 | 246.10 | 269.70 | 44.50 | 44.50 | 298.50 | 22.40 | 8 | 3/4" | 13 | 28.6 |
| 10" | 250 | 406.50 | 30.20 | 304.80 | 323.90 | 49.30 | 49.30 | 362.00 | 25.40 | 12 | 7/8" | 18 | 39.5 |
| 12" | 300 | 482.50 | 31.80 | 365.30 | 381.00 | 55.60 | 55.60 | 431.80 | 25.40 | 12 | 7/8" | 29 | 64 |
| 14" | 350 | 533.50 | 35.10 | 400.10 | 412.80 | 57.20 | 57.20 | 476.30 | 28.50 | 12 | 1" | 39 | 86 |
| 16" | 400 | 597.00 | 36.60 | 457.20 | 469.90 | 63.50 | 63.50 | 539.80 | 28.50 | 16 | 1" | 47 | 103 |
| 18" | 450 | 635.00 | 39.60 | 505.00 | 533.40 | 68.30 | 68.30 | 577.90 | 31.80 | 16 | 1 1/8" | 57 | 126 |
| 20" | 500 | 698.50 | 42.90 | 558.80 | 584.20 | 73.20 | 73.20 | 635.00 | 31.80 | 20 | 1 1/8" | 76 | 167 |
| 24" | 600 | 813.00 | 47.80 | 663.40 | 692.20 | 82.60 | 82.60 | 749.30 | 35.10 | 20 | 1 1/4" | 97 | 214 |
Ready Stock LTCS A350 LF2 Flanges
- Carbon Steel A350 LF2 Raised Face Flanges Exporter
- LTCS A350 LF2 Lapped Joint Flanges
- ANSI B16.5 LTCS A350 LF2 Male & Female Flanges
- Carbon Steel A350 LF2 Large Diameter Flanges
- LTCS A350 LF2 DIN 2566 PN10 Flanges Stockholder
- LTCS A350 LF2 JIS B2220 Flange
- Low Temperature LF2 High Hub Blind Flanges
- Low Temperature A350 LF2 Reducing Flanges
- LTCS A350 LF2 Flanges
- Carbon Steel A350 LF2 AWWA C207 Flange Stockist
- ASME SA350 LTCS LF2 Forged Flanges
- 3 inch LTCS A350 LF2 Welding Neck 300 LBS Flange
- Low Temperature A350 LF2 Threaded Flanges
- Carbon Steel LF2 Class 2500 Flange
- 6 Inch LTCS A350 LF2 Pipe Flanges
- ASTM A350 LF2 Low Temperature Expander Flanges
- LTCS A350 LF2 Tongue & Groove Flanges
- Carbon Steel A350 LF2 Lap Joint Flanges
- LTCS A350 LF2 DN150 PN16 Flange
- ANSI B16.5 LTCS A350 LF2 PN16 Flanges
- Low Temperature A350 LF2 BLRF Flange
- Carbon Steel A350 LF2 Pipe Flanges
- Carbon Steel A350 LF2 BLRF Flange
- Low Temperature LF2 Screwed Flanges
- LTCS A350 LF2 Orifice Flanges
- Low Temperature LF2 BS 4504 Flanges
- LTCS A350 LF2 Blind Flange
- DIN LTCS A350 LF2 Pipe Flanges
- Low Temperature LF2 Loose Flanges
- LTCS A350 LF2 Square Flanges
- Carbon Steel LF2 SWRF Flange
- Class 150 LTCS A350 LF2 Pipe Flange
- LTCS A350 LF2 Welding Neck Flanges
- ASTM A350 Low Temperature LF2 Plate Flanges
- Carbon Steel A350 LF2 Long Weld Neck Flanges
- LTCS A350 LF2 EN 1092-1 Flange
- Carbon Steel LF2 Ring Type Joint Flanges
- ASTM A350 LF2 Socket weld Flanges
- ASTM A350 Low Temperature LF2 SORF Flange
- ASME B16.5 LTCS A350 LF2 Slip on Flanges
- Carbon Steel A350 LF2 JIS B2220 Flange
- ASME B16.5 LTCS A350 LF2 Spectacle Blind Flanges
- Low Temperature CS A350 LF2 Flat Flanges
- Carbon Steel A350 LF2 BS 4504 Flanges
- LF2 Carbon Steel RTJ Flanges Manufacturer
- Low Temperature CS A350 LF2 Flanges
- LTCS A350 LF2 Blind Flanges Supplier in Mumbai
- LTCS A350 LF2 JIS B2220 Flange
- Carbon Steel LF2 Paddle Spacer Flanges
- Low Temperature A350 LF2 WNRF Flange
- Carbon Steel A350 LF2 Flanges Manufacturer
- Low Temperature LF2 Slip On Flanges Distributor
